Technical Specifications |
|
|
Application areas: |
Organ homogenization, grinding, cell disruption, homogenization, material dispersion, preparation, sample mixing, and oscillation |
|
Processing capacity: |
24 samples can be processed simultaneously within 15 seconds, and it can be used with 12- and 24-position liquid nitrogen cryogenic adapters |
|
Compatible sample tubes: |
24*(0.2-0.5ML) /24*2ML /8*(5-15)ML /4*25ML /2*50ML, and various specifications of grinding tubes can be customized |
|
Display mode: |
Touchscreen display (for convenient and intuitive operation) |
|
Ten sets of experimental data can be stored: |
According to different experimental samples, animal heart, spleen, lung, kidney, bone, skin, and hair patterns are set up |
|
Cycle mode: |
According to the set experimental parameters, it can continuously cycle among several preset parameters, further reducing human interference |
|
Anti-vibration principle: |
Innovative anti-vibration principle DHFSTPRP-1, and a special three-dimensional vibration mode of up and down and left and right shaking, the sample moves in 8-shaped three-dimensional space, with innovative grinding ball motion mode to ensure ideal sample processing and instant crushing effect |
|
Maximum feeding size: |
No requirement, adjustable according to the adapter |
|
Final output particle size: |
~5μm |
|
Number of grinding platforms: |
(Accepts more than 2 grinding jars) |
|
Fastening device: |
With automatic centering and positioning |
|
Homogenization speed: |
0~70 Hz/second, working time: 0 seconds to 99 minutes, user can set it themselves |
|
Grinding ball diameter: |
0.01~30mm |
|
Grinding ball material: |
Alloy steel, chrome steel, zirconia oxide, tungsten carbide, and quartz sand |
|
Acceleration: |
Reaching high speed within 2 seconds |
|
Deceleration: |
Reaching low speed within 2 seconds |
|
Noise level: |
<55db |
|
Grinding method: |
Wet grinding, dry grinding, and low-temperature grinding are all possible |
|
Temperature control can be equipped: |
With the ability to upgrade to ultra-low temperature liquid nitrogen cooling or air cooling |
|
Adapter material: |
Polytetrafluoroethylene, alloy steel |
|
Safety instructions: |
With an automatic centering and locking device for safe operation throughout |
|
Grinding kit materials: |
Hard alloy, polytetrafluoroethylene (PTFE), zirconia |
|
Dimensions: |
630*300*480mm |
|
Weight: |
60 Kg |
